We specialize in producing automatic packaging machines, including plastic cup/paper cup packaging machine, hardware parts packaging machine, sleeve type sealer, bag inserter, etc. We have rich experiences and many patents on packaging machines. We offer not only the automatic packaging machines in high quality and efficiency but also reliable after-sales service. Besides, we are flexible to customize and design the automatic packaging procedures and machines of the production lines according to the customers’ requirement.
Our products’ basic specification are high quality machines, which will help you increasing your production efficiency, effectively reduce manpower, reduce labor costs and reduce consumables worn out. In addition to our experienced team, we will assist on installation to make sure machines working smoothly and connecting to production lines successfully.
We also support customized design: According to customers’ specific request, provide the appropriate automatic packaging solutions, with professional design and suggestion on automatic packaging machines and procedures.
| Model | NG-GK-40T |
|---|---|
| Folding Speed | 8-10 pcs/min |
| Carton Size | L250-500 x W200-400 x H150-400mm (L≧W+ 100mm) |
| Power Supply | 380V 50Hz 3 Phaze |
| Power | 3.5KW |
| Air Consumption | 50NL/mm |
| Air Compressing | 4-7kg/cm3 |
| Table Height | 600mm |
| Machine Dimension | L2000 x W1600 x H1900mm |
| Machine weight | 700 KG |
| Model | NG-GK-GS60A |
|---|---|
| Bag Specification | PE Rolling Bag Thickness : 0.04-0.08mm Width: 200-560mm Length : 350-800mm |
| Express Sheet size | Width: Max 100mm width: 100mm, 180mm, or custom made |
| Speed | Max 650 Pkg/H |
| Man-Machine interface | Mouse, Touch Screen, Virtual Keyboard |
| Screen | 12 inch LCD |
| External Communication | Ethernet, USB,RS232 |
| Pneumatic supply | 0.025m3/min 5Kg/ cm3 |
| Power | AC220V, 50/60Hz 1500W |
| Machine dimension (L×w×H) | 1580mm x 850mm x 1420mm |
| Machine weight | 200 Kg |
– The sealing is firm and the packaging is beautiful According to the characteristics of the express bag, the vertical sealing system is specially designed to ensure the bag is strong. The horizontal sealing knife adopts servo control system with high stability and high speed.
– This equipment can seal and cut the conventional express film, can adjust the length of the bag adaptively, without manual intervention and use of adhesive tape, helping the company to save 30% of consumables.
– Full intelligent express strapping machine speed of up to 1200 bags per hour, using servo motor and variable frequency control technology, photoelectric automatic detection, 2D imager automatic scanning, to ensure the precise position of the product, suitable for packaging products of different sizes and shapes.
– The whole machine is based on high-performance industrial control computer, adopts intelligent servo control technology, can intelligently scan and identify product information, automatically adjust the sealing and cutting position according to the product size, quickly adjust the express bag and labeling position, and realize express automatic packaging. Widely used in products of different sizes and shapes.
– The equipment can automatically joint the mainstream ERP system, WMS system and the front section sorting line, without manual intervention, realize the product’s scan code, weighing, film sealing film, automatic printing surface and paste all the process, truly achieve unmanned operation.
– This equipment breaks the traditional multi-machine combination design mode, integrating automatic weighing, code scanning, weighing, error rejection, film sealing, automatic printing express order and automatic express order pasting, without manual intervention, scanning adjustment takes only 0.5 second.
– In order to prevent the occurrence of errors, the express order is automatically generated by the system and automatically printed and pasted without manual intervention.
– Anti-pinch, anti-scalding, anti-misoperation, safe to use.
| Model | NG-GK-GS70A |
|---|---|
| Packing Material Specification | PE Roll film Diameter : Max 300mm Film thickness: 0.05-0.1 mm Film Width: Max 700mm |
| Packaged object | Length: 150-500mm., Height: 10-200mm, Width: 150-450mm (width plus height needs less than 500mm) Weight: Max 15kg |
| Express order size | Width: Max 100mm Length: Min 60mm |
| Packing speed | Max 1200 packs / hour |
| Human machine interface | Touch screen, virtual keyboard |
| Display | 15inch LCD |
| External communication | Ethernet, USB, RS232 |
| Power supply | 3-phase, AC380V, 50/60Hz Power: 10KW |
| Gas source | 0.7-0.9 Mpa |
| Table height | 870mm |
| Equipment size | Length: 4350mm Width: 1300mm Height: 2020mm |
| Machine Weight | 800Kg |
| Model | NG-GQ-P200 Series |
|---|---|
| Machine size (mm) | L3100 x W650 x H1450 (Spec. subject to change without prior notice) |
| Sealing size (mm) | 200 |
| Packing size (mm) | ∅60-115mm |
| Working Height | 810mm |
| Packing capacity | 10-15 packs/min |
| Votage | 1 ⦶ 220V(Depend on customer’s request) |
| Model | NG-GQ-P300 Series |
|---|---|
| Machine size (mm) | L2139 x W728 x H1613 (Spec. subject to change without prior notice) |
| Sealing size (mm) | 300 |
| Packing size (mm) | L60-200 x W40-100 |
| Packing capacity | 10-18 packs/min |
| Voltage | 1 ⦶ 220V(Depend on customer’s request) |
