Standard sizes are as follow. However, if your carton sizes are not in the range shown here, please feel free to contact our sales for special requests. We can customize and support any of your requests.
| SPECIFICATIONS | |
|---|---|
| Conveyor speed | 20m/min |
| Carton Size | L250-600×W150-500×H180-500mm |
| Power Supply | 110/220V 50/60Hz 1Phase |
| Power | 450W |
| Adhesive Tape Width | 48/60/75mm |
| Air Consumption | 300NL/min |
| Air Compressing | 0.6Mpa |
| Table Height | 600+150mm |
| Machine Dimension | L1900×W1140×H1450mm |
| Machine Weight | 300KG |
| SPECIFICATIONS | |
|---|---|
| Conveyor speed | 20m/min |
| Carton Size | L200-600×W150-500×H150-500mm |
| Power Supply | 110/220V 50/60Hz 1Phase |
| Power | 420W |
| Adhesive Tape Width | 48/60/75mm |
| Air Consumption | 50NL/min |
| Air Compressing | 0.6Mpa |
| Table Height | 600+150mm |
| Machine Dimension | L1770×W850×H1520mm |
| Machine Weight | 270KG |
| SPECIFICATIONS | |
|---|---|
| Conveyor speed | 20m/min |
| Carton Size | L200-600×W150-500×H150-500mm |
| Power Supply | 110/220V 50/60Hz 1Phase |
| Power | 420W |
| Adhesive Tape Width | 48/60/75mm |
| Air Consumption | 50NL/min |
| Air Compressing | 0.6Mpa |
| Table Height | 600+150mm |
| Machine Dimension | L1770×W850×H1520mm |
| Machine Weight | 250KG |
