Automatic Carton Erector

Automatic Carton Erector

The automatic carton erector NGGK-50E is a vertical box-opening machine with a speed of 12 boxes/min. The machine adopts PLC+ human-machine interface control. The carton can automatically complete the folding and sealing bottom during the transportation, and it does not stay in the process of folding the bottom. That is to say, the machine can complete the whole process of suction box, molding, folding and sealing bottom of carton at the same time. It is easy to operate, simple to maintain, and stable in performance.

SKU NGGK-50E Category Tags , , ,

Share:

Download Spac PDF
Free Consultation
SPECIFICATIONS
Carton Opening Speed 8-12ctns/min
Carton Size L320-650xW200-500xH150-500mm
Power Supply 110/220V 50/60Hz 1 Phase
Power 240W
Adhesive Tape Width 48/65-72mm(Choose one type)
2inch ,3inch
Carton Storage Quantity 80pcs (800mm)
Air Consumption 450NL/min
Air Compressing 6kg/cm³
Table Height 620+30 mm
Machine dimension L2400×W2050×H1650mm
Machine Weight 500KG
