Automatic Carton Forming Bottom Sealer

NGGK-40

Automatic Carton Forming Bottom Sealer

NGGK-40 and NGGK-40H, a patented product independently researched and developed by us, is a carton forming and bottom sealing packing machine which control by PLC and operate from HIMI system. Machine can support 12 boxes/min and 18 boxes/min. Carton board can be loaded without stopping the machine. So it’s very efficiency and convenient.

SKU NGGK-40 Category Tags , , ,

Share:

Download Spac PDF
Free Consultation
SPECIFICATIONS
Carton Opening Speed 18ctns/min
Carton Size L250-400×W150-350×H100-350mm
Power Supply 110/220V 50/60Hz 1 Phase
Power 240W
Adhesive Tape Width 48/60/75mm (Choose one type)
Carton Storage Quantity 80pcs (800mm)
Air Consumption 450NL/min
Air Compressing 6kg/cm³
Table Height 620+30 mm
Machine dimension L2400×W2050×H1650mm
Machine Weight 500KG
PACKAGE EFFECT

SATISFACTION GUARANTEE

We will make sure you are cared for to the highest standard with our high-performance products. Our clients are the most important part of our family, and our team will do whatever it takes to ensure delivering our customers the right results.

SECOND-TO-NONE SERVICE SUPPORT

Whether it is adhesive material, packaging machine, or automation system, we deliver superior service. Day in and day out with the second-to-none support.

ONE STOP SOLUTION

The secret to our enduring success is two-fold: We partner with a select group of elite suppliers committed to delivering the ideal high performance products for your needs. And then, our team provide you with overall efficient sales support, from materials to machineries and from installation to service after sales.
