Round Bottle Labeling Machine NG-SKPLM Series

Round Bottle Labeling Machine NG-SKPLM Series

Our NG-SKPLM Series is an automatic round bottle labeling machine, where its main application is  for labelling a range of round bottles. NG-SKPLM control is one of the most users friendly machines for automatic labeler machine. The machine is used for full/partial wrap around labeling on different size of round container. It is capable of labeling up to 200 pieces per minutes depending on products and label size.

The bottle sticker labeling machine is manufactured with accurate precision and sturdiness including a product transmission system, label dispenser unit, wrapping unit, programmable logic control panel, electric panel and other advanced features designed to deliver efficiency and effectiveness in the production process. All safety elements of the machine have been considered including covering of all the moving parts. The conveying system is easily adjustable as per the product requirements The makeup components of this equipment have been sourced from high quality manufacturers to guarantee durability and minimum maintenance.

SKU NG-SKPLM Category Tags , ,

Share:

Model NG-SKPLM
Yield(pcs/min) 30-200 (depends on product and label size)
Operating direction Left or Right
Conveyor Speed(m/min) ≤40
Labeling Accuracy ±1.0 mm
The inner diameter of label roll 76 mm
The outer diameter of label roll 350 mm(max)
The suitable size of label Width 15-300 mm length 15-300 mm
The suitable size of labeling objects Can customized
Printer use air 5kg/cm ²
Voltage (In China) AC220V 50/60HZ Single phase
(Can customized as client need)
Power(w) 550W
Weight(kg) 260
Machine size 1800(L) 800 (W) 1500 (H) mm
