Newgate-GK55-CSW Series

Newgate-GK55-CSW Series

NEWGATE- GK55-CSW Series is the fully automatic side sealing and shrinking packaging machine is a medium-speed fully automatic sealing and cutting heat-shrinking packaging machine. It is designed on the basis of fully automatic high-speed side sealing machine according to the different needs of domestic market and customers. It uses photoelectric to automatically detect the product, realizes automatic unmanned packaging, has high work efficiency, and is suitable for products of different sizes and shapes of various packaging types. Vertical cutting system prevent crumples.

  • The cutter adopts vertical system drive to ensure sealing lines straight and tight.
  • With the design of side sealing, the packing length of products is unlimited.
  • The sealing height can be adjusted based on the product height.
  • Widely used in all kinds of products with different sizes and shapes.
SKU GK55-CSW Category Tags ,

Share:

Download Spac PDF
Free Consultation
Model GK5545D GK5530SD
Film POF POF
Packing Speed 10-35pcs/min 20-85pcs/min
Packing Size W+H ≤ 430mm L+H ≤ 550mm (H≤220mm) W≤400 x H≤250mm
Cutter Size / Tunnel Size L635 x W510mm L1500 x W500mm x H300mm
Max Temperature 250 C 200 C
Electrical 200V 50-60Hz 1 Phase 200V/380V 50-60Hz 3 Phase
Power 3.5KW 16KW
Max Current 10A 25A
Air Compressing 5.5-8.5kg/cm3 /
Table Height 850+30mm 850+30mm
Machine Dimension L2040xW1500xH1370mm L1850xW1095xH1325mm
Machine weight 700 KG 650 KG
